Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector

HK Anenerge Co., Limited
Contact Now
    Buy cheap Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector from wholesalers

    Buy cheap Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector from wholesalers
    • Buy cheap Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector from wholesalers
    • Buy cheap Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector from wholesalers
    • Buy cheap Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector from wholesalers

    Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector

    Ask Lasest Price
    Brand Name : OEM/Anenerge
    Model Number : AE-12001000
    Certification : CE Rohs FCC UL SAA CCC GS
    Price : 1-3usd/pcs
    Payment Terms : D/P, T/T, Western Union,Paypal
    Supply Ability : 100000pcs/month
    Delivery Time : 3-5days
    • Product Details
    • Company Profile

    Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector


    EU ac/dc adapter,12v 1a 2a 2.5a wall mount adapter for LED strips,webcam,router,customized Dc connector


    Quick Details
    Place of Origin: Guangdong, China (Mainland)
    Brand Name: OEM/ Anenerge
    Model Number: AE-12002000
    Output Type: AC to DC power adapter
    Connection: Plug In
    color: black or white
    advantage: meet china standards
    output power (max): 12W/24W/30W
    efficiency (max): 85%
    inside: built EMC/EMI filter
    MOQ: 1000pcs
    Usage: CCTV camera,Portable DVD
    DC cable: 1.2m


    Usage

    * LED strip ,LED light ,LED table lamp.

    * Router,amplifier,CCTV camera,

    * Home appliances ,setup box ,speaker,

    * Audio & Video equipments,

    * Wireless communication electronics .

    * Medical equipments

    * Ipad, Tablet PC etc ,Notebook
    * Camera.
    * LCD
    * Electrical toy.

    DC Output Voltage12V± 5%
    DC Output Current2000mA
    DC Output Power24w
    Working Efficency83%
    Adapter Size85*39*31mm (L/W/H)
    Efficiencylevel 5
    Warranty2 years
    Certificates approvedTUV CB CE GS ROHS UL/CUL FCC IECS SAA C-tick
    Input Rated Voltage86Vac~264Vac
    Input Frequency Range47Hz~63Hz
    Safety protectionoutput voltage protection (120%-150% rated output current)
    output current protection (150%-180% rated output current)
    short current protection
    Ripple and Noiseless than 60Mv at full road with 20MHz bandwidth
    DC connector5.5*2.1*11mm (optional)
    DC cable1.5m 2464UL 20AWG cable (optional)
    Operating Temperature0°C - +55°C
    Storage Temperature-20°C - +85°C
    Safety StandardEN60950 EN60601 ESD (EN61000 3-3)
    CAS (60950 ITE/TE,EN60601 Medical) FCC Part 15 subpart B Class 2
    AN/NZS CISPR 22:2006
    Turn On Delay Timeless than 3S (AC:110V and full load)
    Dielectric VoltageA IEC320 three pin input---output(FG)3000Vac one minute
    Input Currentless than 0.5A
    Input Inrush Currentless than 50A
    Leakage Currentless than 5mA
    Standby powerless than 0.3w
    Net Weight156g/pcs
    Gross Weight13.2kg/carton
    Carton Box Size39*31*29cm

    Eu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc ConnectorEu AC / DC Switching Power Adapter 12v 2a 2.5a Customized Dc Connector
