4.2V 12.6V 16.8V Li Ion 18650 Battery Charger / Lead Acid Battery Charger With Green Turn Light

HK Anenerge Co., Limited
Contact Now
    Buy cheap 4.2V 12.6V 16.8V Li Ion 18650 Battery Charger / Lead Acid Battery Charger With Green Turn Light from wholesalers

    Buy cheap 4.2V 12.6V 16.8V Li Ion 18650 Battery Charger / Lead Acid Battery Charger With Green Turn Light from wholesalers
    • Buy cheap 4.2V 12.6V 16.8V Li Ion 18650 Battery Charger / Lead Acid Battery Charger With Green Turn Light from wholesalers
    • Buy cheap 4.2V 12.6V 16.8V Li Ion 18650 Battery Charger / Lead Acid Battery Charger With Green Turn Light from wholesalers
    • Buy cheap 4.2V 12.6V 16.8V Li Ion 18650 Battery Charger / Lead Acid Battery Charger With Green Turn Light from wholesalers

    4.2V 12.6V 16.8V Li Ion 18650 Battery Charger / Lead Acid Battery Charger With Green Turn Light

    Ask Lasest Price
    Brand Name : OEM
    Model Number : AE-42V1A
    Certification : CE Rohs FCC UL SAA TUV
    Price : 1usd/pcs
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 100000pcs/month
    Delivery Time : 3-5days
    • Product Details
    • Company Profile

    4.2V 12.6V 16.8V Li Ion 18650 Battery Charger / Lead Acid Battery Charger With Green Turn Light

    4.2V 12.6V 16.8V li-ion 18650 battery charger,lead acid battery charger,with green turn light


    Use: Standard Battery

    Type: Electric

    Place of Origin: Guangdong, China (Mainland)

    Socket Standard: EU/AU/UK/US

    Product name: 18650 battery charger

    Input Voltage: AC 100~240V 50/60HZ

    Output voltage: 4.2V 12.6V 16.8V DC

    Output current: 1000mA

    Output Power: 12.6W 16.8W

    Protection: Short cricuit/ouerload

    Certificates: CE ROSH FCC UL

    Warranty: 2 Years

    Color: Black

    OEM Service: yes


    ModelAE-42V1A

    Output


    DC output voltage8.4V
    Output voltage tolerance±5%
    Rated output current1.0A
    Output current range0~1.0A
    Output power8.4W
    Ripple and noise100mVp-p
    Line regulation±0.5%
    LED indicatorGreen LED ON <100~150mA
    Charging mode2 stage, CC-CV mode

    Input


    Input voltage range100~240VAC 140~350VDC
    AC input current0.2A/230VAC
    Efficiency82%
    AC inrush current3A/230VAC
    Leakage current<3.5mA
    Frequency range50~60Hz

    Protection

    characteristic



    Over load protection

    105%~150%rated output power
    Protection mode : FOLDBACK limiting output reset: auto recovery

    Environment


    Working temperature0~+50 degree
    Working humidity20%~90% RH non-considering
    Storage Temp,humidity-10~+60 degree
    Temp.coefficient±0.03% /(0~50 degree)
    Vibration10 ~ 500Hz, 2G10min / 1 cycle, duration 60 minutes, each axis

    Safety


    Withstand voltageI/P-O/P:3000 VAC
    Safety standardsEN60950
    Insulation resistanceI/P-O/P:100M Ohms/500VDC/25 degree/70 degree RH
    Harmonic currentCompliance to EN55024, EN61000-3-3
    EMS immunityCompliance to EN61000-3-3

    Others


    Weight/Packing0.1kg/100PCS/12kg
    Dimension74.5*29*78.3MM

    Remark:

    1. All parameters are specified at 230VAC input, rated load, 27 degree 70%RH ambient.
    2. Ripple and noise are measured at 20MHz by using a 12 inch Twisted pair terminated with 0.1u and 47u capacitor.
    3. Tolerance: includes set up tolerance, line regulation, load regulation.
    4. DC voltage : the output voltage set at point measure by plug terminal &50% load.
    5.Line regulation is measured from low line to high line at rated load.
    6.Load regulation is measured from 20% to 100% rated load.
    7.The power supply is considered a component which will be installed into a final equipment .The final equipment must be re-confirmed that it stills meets EMC directives.
