    120 Watt Wall Mount Led Light Power Adapter AC110V-220V For Security System

    Ask Lasest Price
    Brand Name : OEM/Anenerge
    Model Number : AE-12010000
    Certification : CE Rohs FCC UL TUV GS CB SAA KC
    Price : 1-3usd/pcs
    Payment Terms : Western Union,Paypal,T/T
    Supply Ability : 1000000pcs/month
    Delivery Time : 3-5days
    • Product Details
    • Company Profile

    120 Watt Wall Mount Led Light Power Adapter AC110V-220V For Security System

    LED power adapter 12V 10A 120Watt with UL CE marked for LED strips CCTV camera


    100% more than 2 Hour Burn-In Test
    100% 4 times electrical performance test
    100% dropping test from 6 surface
    100% Solder ball vibration test
    100% Hi-Pot Test
    0.3% RMA F.O.C


    Product Electric Parameters
    Input specificationInput voltageAC110V-220V
    Input frequency50-60Hz
    Input surge20A@120VAC 40A@230VAC
    Output specificationOutput voltage can be adjusted±10%
    Start-up time<1S(input230V Io=100%)
    keep time>20mS (input230V,Io=100%)
    Voltage regulation(Full load) <0.5%
    Protection functionOverload protection105% - 150% rated power, automatic recovery
    Over-voltage protection105% - 150% of the rated voltage
    Insulation intensityInput---output1500VAC/1min
    Input---ground1500VAC/1min
    Input---ground500VAC/1min
    Safety standardsAccording with GB4943, UL60950-1,EN60950-1 standards.
    E M C standardsAccording with GB9254, EN55022 class A EN61347-2-13:2008 standards
    Environmentalworking temperature- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
    Storage temperature- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
    height above sea level<2000M
    Cooling methodCooling methodNatural cooling air convection
    Product Type Table
    Product modeloutput specificationripple, noiseefficiency
    A-24-12CE24V5A100mV85%
