    100-240VAC Ac Dc Switching Adapter Power Supply , Ac Dc Portable Power Adapter

    12v 8a 96w desktop power adapter 100-240VAC switching AC DC power supply with CE UL


    1. Input : AC 100-240V 50/60HZ


    2. Output: 12V 8A 96W


    3. Plug option: AU EU UK US AUS CN


    4. Inlet type: C6 C8 C14


    5. AC/DC cable length: 1.2M/1.5M


    6. Size:138*60*34mm


    7. DC Jack size: 5.5*2.5mm or 5.5*2.1mm


    8. MOQ: 500pcs


    9. Package: white box+carton


    10. Delivery:1-3 workdays for samples


    11. Warranty: 3 years


    12. Certification: UL/CUL CE CB FCC GS TUV PSE ROHS SAA KC


    Input CharacteristicsRated Voltage100~240Vac
    Variation Range90-264Vac
    Rated Frequency:50/60Hz
    Variation Frequency47-63Hz
    AC Current1.8Amps max
    AC Leakage Current0.25mA

    Output Characteristics


    12V 8A 96W
    Ripple and Noise:120mV p-p
    Turn- on Delay Time2Seconds Max.at 115Vac input and output Max.load
    Rise time40 mS Max.at 115Vac input and output Max load
    Hold-up Time5 mS Min.at 115Vac input and output Max.Load
    Efficiency80% Min, At 115/230Vac input voltag
    Output Overshoot/ Undershoot10% max
    Protectionover voltage protection:120%min
    over current protection:120%min
    Short-circuit protection:automatic recovery
    Operation Temperature0°C to 40°C
    Environment RequirementsStorage Temperature-20°C to +80°C
    Relative Humidity5%(0°C )~90%(40 °C)RH
    Operating:IEC 721-3-3 3M3
    VibrationTransportation:IEC 721-3-2 2M2
    Axes,10 cycles per axis.

    Dropping Packed


    1M for wall mount type and 760mm for desktop type as above described

    Reliability Requirements


    Burn-in2 hours under normal input and 80%rated load at 30°C ±10°C
    MTBF Qualificationat least 50,000 hours at 25°C
    Mechanical RequirementEnclosuresize: L138xW60xH34mm
    Input ConnectorC14 C6 C8
